19
Technical Information
Service Manual
1
2
3
4
5
6
7
8
9
10
11
12131415
● Top view
Outdoor Unit
● Bottom view
No. Name
1 Compressor
2 Reactor 2
3 Reactor 1
4 Chassis electric heating
5 Compressor electric heating
6 4-way valve
7 DC fan
8 Earthing wire
9
Communication wire
10 Neutral wire
11 Live wire
12 Electronic expansion valve
13 Temperature sensor
14 Overloard
15 DRED
