85
Installation and Maintenance
Service Manual
Procedure
Step
Screw
Condenser
Remove 3 foot nuts on compressor, and then
remove the compressor.
Note:
Protect the ports of discharge pipe and
suction pipe to avoid foreign objects to
enter it.
Remove one screw xing the condenser,
then remove the condenser.
Foot nuts
Compressor
16. Remove compressor
17. Remove condenser
