Installation and Maintenance
Service Manual
No.
Description
Part Code
Qty
GWH09YD-S6DBA2A/I
Product Code CB466N00102
1
Front Panel 00000300008303 1
2
Filter Sub-Assy 11122089 2
3
Front Case Sub-Assy 00000200060 1
4
Axile Bush 10542036 2
5
Guide Louver 10512501 1
6
Ring of Bearing 26152025 1
7
O-Gasket of Cross Fan Bearing 76512203 1
8
Cross Flow Fan 10352060 1
9
Air Louver(Manual) 10512501 1
10
Helicoid Tongue 26112512 1
11
Rear Case assy 00000100177 1
12
Evaporator Support 24212177 1
13
Evaporator Assy 011001000472 1
14
Wall Mounting Frame 01362026 1
15
Drainage Hose 05230014 1
16
Cold Plasma Generator 1114001602 1
17
Rubber Plug (Water Tray) 76712012 1
18
Connecting pipe clamp 2611218801 1
19
Crank 73012005 1
20
Stepping Motor 1521240212 1
21 Motor Press Plate 26112511 1
22 Fan Motor 15012136 1
23 Screw Cover 2425201726 3
24
Electric Box Assy 100002004024 1
25 Electric Box 2011221102 1
26 Lower Shield of Electric Box 01592139 1
27 Shield Cover of Electric Box 01592176 1
28 Display Board 300001000095 1
29 Main Board 300002000858 1
30 Terminal Board 42011233 1
31 Electric Box Cover 20112209 1
32 Electric Box Cover2 20112210 1
33 Shield Cover of Electric Box Cover 2 01202000099 1
34 Connecting Cable 4002052317 0
35 Connecting Cable / /
36 Temperature Sensor 3900031302 1
37 Remote Controller 305001000139 1
38 Jumper 4202021911 1
39 Detecting Plate 000409000001 1
Above data is subject to change without notice.
