GWH09YD-S6DBA2A/O GWH12YD-S6DBA2A/O
Product Code CB466W00100 CB466W00200
1 Front Grill 22413046 22413046 1
2 Cabinet 01433034P 01433034P 1
3 Axial Flow Fan 10333011 10333011 /
4 Brushless DC Motor 1501308511 1501308511 1
5 Clapboard Sub-Assy 01235094 01235094 1
6 Left Side Plate 01303169P 01303169P 1
7 Valve Cover 22243005 22243005 1
8 Main Board 300027000056 300027000056 1
9 Electric Box Assy 100002000997 100002000997 2
10 Coping 01253034P 01253034P 1
11 Rear Grill 01475022 01475022 1
12 Condenser Assy 011002000422 011002000422 1
13 Compressor and Fittings 00900100022901 00900100022901 1
14 4-Way Valve Assy 030152000214 030152000214 1
15 Cut off Valve 07130239 07130239 1
16 Cut off Valve 071302391 071302391 1
17 Drainage Joint 26113009 26113009 1
18 Big Handle 2623343106 2623343106 1
19 Valve Support Sub-Assy 01710400005P 01710400005P 1
Above data is subject to change without notice.
