62
Installation and Maintenance
Service Manual
NO.
Description
Part Code
Qty
GWH18KG-K3DNA6G/I
(Cold Plasma)
GWH18KG-K3DNB2G/I
(Cold Plasma)
Product Code CB146N36000 CB409N02500
1 Front Panel 20012495 20012731 1
2 Filter Sub-Assy 11122104 11122104 2
3 Screw Cover 242520041 242520041 1
4 Front Case Assy 20012497 20012497 1
5 Guide Louver 10512140 10512140 1
6 Air Louver 10512160 10512160 2
7 Helicoid tongue 26112232 26112232 1
8 Left Axile Bush 10512037 10512037 1
9 Rear Case assy 22202154 22202154 1
10 Rubber Plug (Water Tray) 76712012 76712012 1
11 Ring of Bearing 26152022 26152022 1
12 O-Gasket sub-assy of Bearing 7651205102 7651205102 1
13 Evaporator Support 24212119 24212119 1
14 Cold Plasma Generator 1114001602 1114001602 1
15 Evaporator Assy 01002320 01002320 1
16 Wall Mounting Frame 01252484 01252484 1
17 Cross Flow Fan 10352036 10352036 1
18 Motor Press Plate 26112231 26112231 1
19 Fan Motor 15012146 15012146 1
20 Connecting pipe clamp 2611216401 2611216401 1
21 Drainage hose 0523001407 0523001407 1
22 SteppingMotor 15012086 15012086 1
23 Crank 10582070 10582070 1
24 Electric Box Assy 10000201021 10000201021 1
25 Electric Box 20112103 20112103 1
26 Axile Bush 10542036 10542036 1
27 Indicator Light Cover 22242084 22242084 1
28 Indicator shield cover 22242083 22242083 1
29 Terminal Board 42011233 42011233 1
30 Jumper 4202300115 4202300115 1
31 Electric Box Cover2 20122142 20122142 1
32 Main Board 30138000408 30138000408 1
33 Display Board 30568112 30568112 1
34 Shield Cover of Electric box Cover 01592088 01592088 1
35 Electric Box Cover 20122123 20122123 1
36 Shield cover of Electric Box 01592087 01592087 1
37 Power Cord / / /
38 Connecting Cable 4002052317 4002052317 0
39 Remote Controller 305100611 305100611 1
Above data is subject to change without notice.
