Haier 1U09BS2ERA User Manual

10
Specifications
Dimensions(W×D×H) mm 795×192×265
Packaged Dimensions(W×D×H) mm 871×304×360
weight Kg 9.4
Gross weight Kg 11
Operation Sound H/M/L dB(A) 51/46/42/39 37/34/31/27
Sound Power H(cooling/heating) dB(A) 60 61
Outdoor unit
Casing color / White
compressor
Type / Rotary Compressor
Model / DA89X1C-20FZ
Motor output W 690
Oil type / ESTER OIL VG47
Oil charge ml 370
refrigerant
model / R410A
charge kg 0.85 1.1
Fan speed
H
km/h
880 880 880 880
L 300 300 300 300
Fan type / Axial fan
Fan motor output W 30
Running current (rate) A 8.5
Power consumption (rate) W 1869
Dimensions(W×D×H) mm 780×245×540
Packaged Dimensions(W×D×H) mm 930×340×614
weight Kg 29 31.5
Gross weight kg 32 34.5
Operation Sound H/M/L dB(A) 60 61
Sound Power H(cooling/heating) dB(A) 60 61
Remote controller
Model / YR-HD01
picture /
Note: the data are based on the conditions shown in the table below
cooling heating Piping length
Indoor: 27 DB/19 WBćć
Outdoor: 35 DB/24 WBćć
Indoor:20 DBć
Outdoor: 7 DB/6 WBćć
5m
Domestic air conditioner
Conversation formulae
Kcal/h= KW×860
Btu/h= KW×3414
cfm=m³/min×35.3
