Serial No. Temperature scope Frequency limitation
1
Twh
16
Max_hz1 34HZ
2
16<Twh
24
Max_hz2 40 HZ
3
24<Twh
32
Max_hz3 62 HZ
4
32<Twh 44
Max_hz4 72 HZ
ZH045zh_xaM44>hwT5
Remarks: the above are not only the maximum frequency limitations of the complete appliance
which are affected by the environment, but also the maximum ability limitation of the system.
When the starting ability is not the maximum, its maximum frequency limitation is calculated by
the following equations:
The frequency limitation which is affected by the temperature and under the condition of actual
ability
the actural running system ability the maximum frequency which is limited by the
temperature and under the condition of maximum ability
the maximum designing ability of the
system
T= Ti*Pi / Pi ( Ti=|Tst_i-Tnh_i the indoor environment temperature| ;Pi ithe
ability of the indoor unit)
Refrigeration/dehumidification:
Heating mode
K= Ki/the number of running machines
The calculation of the actual output frequency: when there is no healthy airflow: F =F-ED-*
P K
When the healthy airflow has been set: F =F-ED-*
P K airflow speed K healthy airflow
When refrigerating, it is needed to satisfy IN <F<
When heating, it is needed to satisfy IN r< F< r
7.1.2 The outdoor fan control (exchange fan)
When the fan is changed among every airflow speed (including stop blowing), in order to avoid
the airflow speed from skipping frequently, it must be kept under each mode for over 30 seconds,
and then it can be changed to another mode (when refrigerating, the time is changed to 15
seconds).
T
<1
1 2 3
>=4
The percentage of
the rated frequency P
50% 70% 100% 120% 140%
T
<1
1 2 3
>=4
The percentage of the
rated frequency P
50% 70% 100% 114% 180%
The indoor set
airflow speed
Breeze Low Medium High Strong Quiet Healthy
airflow
The percentage
of the rated
frequency Ki
70
80% 90% 100% 120% 70% 70%
