INSTALLATION INSTRUCTIONS
COMPATIBILITY MATRIX FOR MULTI ZONE DUCTLESS SYSYTEM
2U18MS2HDA1 & 2U20EH2VHA
Zones Combinations
Unit A Unit B
Two Zone
Unit A
Unit B
7K 7K
7K 9K
9K 9K
7K 12K
9K 12K
12K 12K
3U24MS2HDA1 & 3U24EH2VHA
Combinations
Zones Unit A Unit B Unit C Zones Unit A Unit B Unit C
Two Zone
Unit B
Unit C
— 7K 7K Three Zone
Unit A
Unit B
Unit C
7K 7K 7K
— 7K 9K 7K 7K 9K
— 9K 9K 7K 9K 9K
— 7K 12K 7K 7K 12K
— 9K 12K 9K 9K 9K
— 12K 12K 7K 9K 12K
— 7K 18K 9K 9K 12K
— 9K 18K 7K 12K 12K
— 12K 18K 7K 7K 18K
— — — 9K 12K 12K
4U36MS2HDA1 & 4U36EH2VHA1
Zones Combinations
Unit A Unit B Unit C Unit D Zones Unit A Unit B Unit C Unit D
Two Zone
Unit C
Unit D
— — 9K 18K Four Zone
Unit A
Unit B
Unit C
Unit D
7K 7K 7K 7K
— — 12K 18K 7K 7K 7K 9K
— — 7K 24K 7K 7K 9K 9K
– – 9K 24K 7K 7K 7K 12K
— — 12K 24K 7K 9K 9K 9K
— — 18K 18K 7K 7K 9K 12K
— — 24K 18K 9K 9K 9K 9K
— — 24K 24K 7K 9K 9K 12K
Three
Zone
Unit B
Unit C
Unit D
— 9K 9K 9K 7K 7K 12K 12K
— 7K 9K 12K 7K 7K 7K 18K
— 9K 9K 12K 9K 9K 9K 12K
— 7K 12K 12K 7K 9K 12K 12K
— 7K 7K 18K 7K 7K 9K 18K
— 9K 12K 12K 9K
9K 12K 12K
— 7K 9K 18K 7K 9K 9K 18K
— 9K 9K 18K 7K 12K 12K 12K
— 12K 12K 12K 7K 7K 12K 18K
— 7K 12K 18K 7K 7K 7K 24K
— 7K 7K 24K 9K 9K 9K 15K
— 9K 12K 18K 9K 12K 12K 12K
— 7K 9K 24K 7K 7K 9K 24K
— 9K 9K 24K 9K 9K 12K 18K
— 12K 12K 18K 12K 12K 12K 12K
— 7K 12K 24K
— 9K 12K 24K
— 12K 12K 24K
— 12K 18K 18K
