1. Introduction
2
User Manual
1.1 Product Description
The Haier H3PH Series is designed for residential hybrid systems, which can work with
batteries to optimize self-consumption.
The unit can operate in both off- and on-grid modes.
This manual covers the Haier H3PH Series inverter model listed below:
H3PH-1J5K-EU, H3PH-1J6K-EU, H3PH-1J8K-EU, H3PH-1J10K-EU
Figure 1.1
Front side view
Figure 1.2 Bottom side view
DC Switch
AC Grid Port
AC Backup Port
Data Logging
Stick (Optional)
AntennaPV Input
Battery Input
AC- GR IDAC- BA CK UP
ANT EN NA
COM
PV1 PV2 PV3 PV4 BAT
DC Switch
Communication

Haier H3PH-1J10K-EU Specifications

General

Brand	Haier
Model	H3PH-1J10K-EU
Category	Inverter
Language	English
