Service Manual
Model No.: HL22XSLW2
22
Connecting Headphones
You can connect a set of headphones to your set if you wish to watch a
TV programmer without disturbing the other people in the room.
Plug a set of headphones into the 3.5mm
mini-jack socket on the rear panel of the set.
Note˖
Ƶ Prolonged use of headphones at a high volume
may damage your hearing.
Ƶ You will not receive sound from the speakers
when you connect headphones to the system.
Analog Audio Cable
(Stereo to RCA type)
(not supplied with the product)
YPbPr
Audio In
LR
Headphone
out
S- VIDEO
Power source
TO USE AC POWER SOURCE
Use the AC polarized line cord provided for operation on AC.
Insert the AC cord plug into a standard polarized AC outlet.
NOTES:
Ƶ Never connect the AC line cord plug to other than the specified voltage.
Use the attached power cord only.
Ƶ If the polarized AC cord does not fit into a non-polarized AC outlet,
do not attempt to file or cut the blade. It is the user`s responsibility to have an
electrician replace the obsolete outlet.
Ƶ If you cause a static discharge when touching the unit and the unit fails to
function, simply unplug the unit from the AC outlet and plug it back in. The unit
should return to normal operation.
Polarized AC Cord Plug
AC Outlet
Wider Hole
and Blade
To Next Page
