Service Manual

Model No.: HL22XSLW2

1. Always unplug the receiver AC power cord from the AC power source before:

a. Removing or reinstalling any component, circuit board module or any other receiver

assembly.

b. Disconnecting or reconnecting any receiver electrical plug or other electrical connection.

c. Connecting a test substitute in parallel with an electrolytic capacitor in the receiver.

CAUTION:

A wrong part substitution or incorrect polarity installation of electrolytic capacitors

may result in an explosion hazard.

2. Test high voltage only by measuring it with an appropriate high voltage meter or other voltage

PHDVXULQJGHYLFH'90)(7920HWFHTXLSSHGZLWKDVXLWDEOHKLJKYROWDJHSUREH

Do not test high voltage by "drawing an arc".

3. Do not spray chemicals on or near this receiver or any of its assemblies.

4. Unless specified otherwise in this service manual, clean electrical contacts only by applying

the following mixture to the contacts with a pipe cleaner, cotton-tipped stick or comparable non-

abrasive applicator; 10% (by volume) Acetone and 90% (by volume) isopropyl alcohol (90%-99%

strength).

CAUTION:

7KLVLVDÀDPPDEOHPL[WXUH

8QOHVVVSHFL¿HGRWKHUZLVHLQWKLVVHUYLFHPDQXDOOXEULFDWLRQRIFRQWDFWVLVQRWUHTXLUHG

Capacitors may result in an explosion hazard.

5. Do not defeat any plug/socket B+ voltage interlocks with which receivers covered by this

VHUYLFHPDQXDOPLJKWEHHTXLSSHG

6. Do not apply AC power to this instrument and/or any of its electrical assemblies unless all

solid-state device heat sinks are correctly installed.

7. Always connect the test receiver ground lead to the receiver chassis ground before connecting

the test receiver positive lead.

Always remove the test receiver ground lead last. Capacitors may result in an explosion

hazard.

8VHZLWKWKLVUHFHLYHURQO\WKHWHVW¿[WXUHVVSHFL¿HGLQWKLVVHUYLFHPDQXDO

CAUTION:

'RQRWFRQQHFWWKHWHVW¿[WXUHJURXQGVWUDSWRDQ\KHDWVLQNLQWKLVUHFHLYHU

9. Remove the antenna terminal on TV and turn on the TV.

10. Insulation resistance between the cord plug terminals and the eternal exposure metal should

be more than Mohm by using the 500V insulation resistance meter.

,IWKHLQVXODWLRQUHVLVWDQFHLVOHVVWKDQ0RKPWKHLQVSHFWLRQUHSDLUVKRXOGEHUHTXLUHG

If you have not the 500V insulation resistance meter, use a Tester. External exposure metal:

Antenna terminal Headphone jack.
