Harman Kardon AVR 360 Service Manual

Level Ref. # Part Numbe
r
Description
Drawin
g
No
(
Value
)
Qt
y
UM
0,2 CGB1A219Z BADGE , AVR360 1EA
0,2 CGL1A222 INDICATOR , VOLUME AVR130/230/330 1 EA
0,2 CGR3A436 COVER , JACK A 1EA
0,2 CGR3A437 COVER , JACK B 1EA
0,2 CGU1A318Y ORNAMENT , VOLUME AVR255 1 EA
0,2 CGU1A410A25M WINDOW , FIP 1EA
0,2 CGX1A338MBC63 CAP , VOLUME 1EA
0,2 CGX1A391C66 ORNAMENT , AL A AVR350 1 EA
0,2 CGX1A392C66 ORNAMENT , AL B AVR350 1 EA
0,2 CGX2A390C66S SHEET , AL FRONT 1 EA
0,2 CKC6B145S60 CABINET , TOP AVR350 1 EA
0,2 CMH1A214 HOLDER , VOLUME AVR130/230/330 1 EA
0,2 CMZ2A090 SHEET , VOLUME 1EA
0,2 CQB1A549Y LABEL , ATTENTION DVD48 1 EA
0,2 CQB1A622 LABEL , SERIAL NO 1 EA
0,2 CTB3+8JFZR SCREW 17 EA
0,2 CTB4+6FFZR SCREW 6EA
1 CARTAVR360E-HK REMOCON ASS'Y (57KEY) AVR360 1 EA
1 CHE154 CLAMPER , ARM 0,12 M
1 CJXAVR340MICRO MICRO PHONE ASS'Y 1 EA
1 CPG1A891U BOX , OUT CARTON 1 EA
1 CPP1A081Z BAG,POLY SET 1EA
1 CPS5A564Z PAD , SNOW L AVR155 1 EA
1 CPS5A565Z PAD , SNOW R AVR155 1 EA
1 CQB1A907Z LABEL , BAR CODE AVR154 1 EA
1 CQB1A928Z LABEL , MADE IN PRC 2 EA
1 CQS1A001 RIBON , BAR CODE SONY(TR-4070) 0,12 M
1 CQXAVR360/240 INSTRUCTION MANUAL ASS'Y 1 EA
0,2 CQB1A971 LABEL , BAR CODE(MANUAL) 1 EA
0,2 CQE1A220Z SHEET , FRONT COVER AVR130/230BK 1 EA
0,2 CQE1A411Z SHEET , BATTERY HARMAN 1 EA
0,2 CQX1A1433Z MANUAL , INSTRUCTION 1 EA
0,2 CSA1A018Z FM 1 POLE ANT 1EA
0,2 CSA1A032Z ANT , AM LOOP 1EA
1 CRE1A037 LOCKER SH08M790BO 14 EA
Level
Ref. # Part Numbe
r
Description
Drawin
g
No
(
Value
)
Qt
y
UM
0,2 CGWAVR360/24
0
FRONT PANEL ASS'
Y
1E
A
..3 CBT2A1064 KNOB , STANDBY 1EA
..3 CBT2A1065 KNOB , BACK 1EA
..3 CGB1A158Y BADGE , FRONT HARMAN/KARDON 1 EA
..3 CGL1A265Y INDICATOR , POWER AVR155 1 EA
..3 CGW3A447RHVB24 PANEL , FRONT 1EA
..3 CHG1A309 RUBBER 1EA
..3 CHR301 CLAMPER 6EA
..3 CMC1A372 PLATE , SHIELD 2EA
..3 CMC2A323 PLATE , SHIELD 1EA
..3 CMC2A326 PLATE , EARTH AVR350 3 EA
..3 CMC2A338 PLATE , EARTH AVR350 2 EA
..3 CMD1A555 BRACKET , SIDE (L) 1 EA
..3 CMD2A443 BRACKET , SIDE 1EA
..3 CMH1A297 HOLDER , USB 1EA
..3 CMH2A215 HOLDER , LED AVR350 1 EA
..3 CMZ1A127 FILTER , FIP AVR255 1 EA
..3 CPE1A009 SHEET , BLIND 1EA
..3 CTB3+8JFZR SCREW 28 EA
..3 CTWS3+10GR SCREW 1EA
..3 CB72 CWC4C4A31B250B08 CARD , CABLE (31p,1.25mm,250mm,08mm) 1 EA
Level
Ref. # Part Numbe
r
Description
Drawin
g
No
(
Value
)
Qt
y
UM
0,2 CUAAVR360/24
0
BOTTOM CHASSIS ASS'
Y
1E
A
..3 CFNCF12625SA MOTOR , FAN(60X60X25MM) 1 EA
..3 CHD1A012ZR SCREW , SPECIAL 2 EA
..3 CHD1A023R SCREW , SPECIAL 4 EA
..3 CHD1A036FZR SCREW , SPECIAL 2 EA
..3 CHD1A065R SCREW , FLAT(2.6X4) 2 EA
..3 CHD4A012R SCREW , SPECIAL 5 EA
..3 CHE170 HOLDER , PCB 2EA
..3 CHE36-3 CLAMPER , WIRE 1EA
..3 CHG1A104Z CUSHION , RUBBER 2 EA
..3 CHG1A113 RUBBER 3EA
..3 CHG1A160Z CUSHION , RUBBER 1 EA
..3 CHG1A373 CUSHION , FOOT AVR350 4 EA
..3 CHG1A462 CUSHION , RUBBER 1 EA
..3 CHS1A032 TAPE , HEMELON 4EA
..3 CJA2B044ZA CORD , POWER (KENIC) EUR 16A 250V 1 EA
..3 CKF5A398Z PANEL , REAR 1EA
..3 CKL1A094 FOOT , A AVR350 2EA
..3 CKL1A095 FOOT , B AVR350 2EA
..3 CMD1A506 BRACKET , FAN AVR330/AVR4600 1 EA
..3 CMD1A702 FRAME , BOTTOM 1EA
..3 CMD2A636 BRACKET , PCB 1EA
AVR360/230 Electrical & Mechanical Parts List
FRONT PANEL ASS
Y
BOTTOM CHASSIS ASS'
Y
harman/kardon
AVR 360/230 Service Manual
Page 13 of 138

Harman Kardon AVR 360 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.07 %
Power output per channel (1KHz@6 Ohm)	130 W
Power output per channel (20-20KHz@8 Ohm)	55 W
Headphone outputs	1
Headphone connectivity	-
HDMI in	4
Digital audio optical in	3
Product color	Black, Silver
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD, DTS-HD Master Audio
Handheld remote control	No
Apple docking compatibility	Not supported
Connectivity technology	Wired
Supported radio bands	AM, FM
Preset stations quantity	30

Weight and Dimensions

Depth	382 mm
Width	440 mm
Height	165 mm
Weight	13400 g
