INFINITY REF551a SPARE PARTS LIST
Pos. No. P/N Description QTY
1 MK0101100765 LOGO COVER PC REF551a 1
2 MK0101100766 LOGO BRACKET PC REF551a 1
3 88MA03200784 MAIN PCBA CLUB5501/REF551a 1
9 SG0101100064 3PIN POWER TERMINAL REF551a 1
12 MK0101400707 FUSE COVER CLUB5501/REF551a 1
15 SG0101100065 4PIN SPEAKER TERMINAL REF551a 1
18 MK0101100763 2PIN RCA COVER REF551a 1
21 88LE03200394 LED BOARD REF551a 1
C28, C34, C35 020513000385 CAP. 3300uF/25V ±20% CLUB5501/REF551a 3
C50, C55 020513000446 CAP. 2200uF/80V D25*25 CLUB5501/REF551a 2
CN1 CN3
120903000124
POWER SOCKET 1P CLUB5501/REF551a
2
CN1
,
CN3
120903000124
POWER
SOCKET
1P
CLUB5501/REF551a
2
CN2,CNA1, CNB1,
CNC1, CND1
120903000125 SPEAKER JACK 1P CLUB5501/REF551a 5
D14 040503000018 Bridge Rectifiers MUR1620CT CLUB5501/REF551a 1
D15 040503000017 Bridge Rectifiers MUR1620CA CLUB5501/REF551a 1
M1, M2, M3, M4 050303000014 IRF3205 110A 50V CLUB5501/REF551a 4
Q15, Q16, Q20,
050403000005
IRFB 38N20D CLUB5501/REF551a
4
,,,
Q21
050403000005
IRFB
38N20D
CLUB5501/REF551a
4
RCA1 120203000057 RCA JACK CLUB5501/REF551a 1
SW1 110603000024 TEMP. SWITCH JUC-31F CLUB5501/REF551a 1
SW3 221103000001 RELAY 12A/120VAC 12VDC CLUB5501/REF551a 1
SW4 110103000060 SLIDE SWITCH 4P3T CLUB5501/REF551a 1
SW5 110103000017 BAND SWITCH 2P2T CLUB5501/REF551a 1
SX1,SX2,SX3,SX4 040703000055 STATIC INHIBITOR CLUB5501/REF551a 4
T1 200403000223 TRASFO. D40 3.5:14 CLUB5501/REF551a 1
U14 060103000810 IC HT7533 20uA CLUB5501/REF551a 1
U16 060103001602 IC SN8P2751P8AD W/S.W. CLUB5501/REF551a 1
U18,U20 060103000359 IC 4558 SOP8 CLUB5501/REF551a 2
U2,U3 060103001420 IC 7812 CLUB5501/REF551a 2
U4
060103001419
IC 7912 CLUB5501/REF551
1
U4 060103001419 IC 7912 CLUB5501/REF551a 1
U5 060103000383 IC TL494C CLUB5501/REF551a 1
U6 050703000019 OPT. COUPLER TLP185 4P CLUB5501/REF551a 1
U7 060103000026 IC IRS2092 SOIC16N CLUB5501/REF551a 1
U8, U11, U13 060103001125 IC TL074 CLUB5501/REF551a 3
VR1,VR2,VR3 010703000252 POTENTIOMETER B20K CLUB5501/REF551a 3
121103000099 RCA TERMINAL 1P CLUB5501/REF551a 2
140203000050 FUSE 30A 32V CLUB5501/REF551a 2
LS0201000323 HEXAGON SCREW M4X55.8 CLUB5501/REF551a 4
MP0501000126 NAMEPLATE 85.5*55.5*0.35mm REF551a 1
CH0102000617 BEAUTY BOX REF551a 1
