IMPORTANT: Make sure the
subwoofer amplifier is turned OFF before
setting the SSI switch. Do not change the
switch position while the subwoofer
amplifier is operating. Doing so could
damage the amplifier.
CONNECTING THE
AMPLIFIER
The subwoofer connectors are compatible
with quick-disconnect (not supplied) or
soldered connections. The recommended
wire gauge is between 14AWG and 8AWG,
depending on the length of the wire run
between the amplifier and woofer.
Heavier gauge wire is preferred for runs
over 6' (2m).
DIAMETER: 10" (254MM)
S
ENSITIVITY (2.83V @ 1M): 92dB
P
OWER HANDLING: 250Wrms (1000W PEAK)
F
REQUENCY RESPONSE:30HZ~ 175HZ
NOMINAL 2 OR 4 OHMS
VOICE-COIL DIAMETER: 2" (50MM)
D
IMENSIONS:
V
ENTED-BOX VOLUME (INCLUDES DRIVER/PORT DISPLACEMENTS)
S
EALED-BOX VOLUME (INCLUDES DRIVER DISPLACEMENT)
S
PECIFICATIONS
V
BOX
= 0.50 ft
3
(14.20 liters)
(side view)
diameter = 3" (76mm)
length = 11.3"
287mm
V
BOX
= 1.5 ft
3
(42.5 liters)
(side view)
VOICE-COIL DC RESISTANCE:R
EVC
(OHMS) . . . . . . . . 2.00 . . . . . . . . . 4.30
V
OICE-COIL INDUCTANCE @ 1KHZ:L
EVC
(MH) . . . . . . . . . 1.21 . . . . . . . . . 0.77
D
RIVER RADIATING AREA:S
D
(IN
2
) . . . . . . . . . . 51.17 . . . . . . . . 51.17
S
D
(CM
2
)......... 330.10....... 330.10
M
OTOR FORCE FACTOR:BL. . . . .. . . . . 10.20 . . . . . . . . 13.60
C
OMPLIANCE VOLUME:V
AS
(FT
3
). . . . . . . . . . 1.14 . . . . . . . . . 1.08
V
AS
(LITERS) . . . . . . . 32.30 . . . . . . . . 30.60
S
USPENSION COMPLIANCE:C
MS
(µM/N)......210.00........200.00
M
OVING MASS,AIR LOAD:M
MS
(GRAMS)...... 134.00....... 133.90
F
REE-AIR RESONANCE:F
S
(HZ) . . . . . . . . . . 29.90 . . . . . . . . 30.70
M
ECHANICAL Q: Q
MS
. . . . . . . . . . . . . . 4.10 . . . . . . . . . 2.60
E
LECTRICAL Q: Q
ES
. . . . . . . . . . . . . . 0.48. . . . . . . . . . 0.60
T
OTAL Q: Q
TS
. . . . . . . . . . . . . . 0.43 . . . . . . . . . .0.49
M
AGNETIC-GAP HEIGHT:H
AG
(IN) . . . . . . . . . . . 0.24. . . . . . . . . . 0.24
H
AG
(MM) . . . . . . . . . . 6.00. . . . . . . . . . 6.00
V
OICE-COIL HEIGHT:H
VC
(IN)...........0.96 . .. .......0.96
H
VC
(MM) . . . . . . . . . 24.50 . . . . . . . . 24.50
M
AXIMUM EXCURSION:X
MAX
(IN) . . . . . . . . . . 0.36 . . . . . . . . . 0.36
X
MAX
(MM) . . . . . . . . 9.25 . . . . . . . . . 9.25
2Ω 4Ω
TECHNICAL DATA
DIAMETER: 12" (305MM)
S
ENSITIVITY (2.83V @ 1M): 93dB
P
OWER HANDLING: 275Wrms (1100W PEAK)
F
REQUENCY RESPONSE:25HZ~ 175HZ
NOMINAL 2 OR 4 OHMS
VOICE-COIL DIAMETER:
D
IMENSIONS:
V
ENTED-BOX VOLUME (INCLUDES DRIVER/PORT DISPLACEMENTS)
S
EALED-BOX VOLUME (INCLUDES DRIVER DISPLACEMENT)
S
PECIFICATIONS
V
BOX
= 0.75 ft
3
(21.20 liters)
(side view)
Port
f
B
= 30.0Hz
diameter = 4" (102mm)
length = 11.7"
298mm
V
BOX
= 2.5 ft
3
(70.8 liters)
(side view)
THIELE-SMALL PARAMETERS
2Ω 4Ω
REFERENCE 1070 REFERENCE 1270
2" (50MM)
THIELE-SMALL PARAMETERS
(T
M
)
V
OICE-COIL DC RESISTANCE:R
EVC
(OHMS) . . . . . . . . 2.00 . . . . . . . . . 4.40
V
OICE-COIL INDUCTANCE @ 1KHZ:L
EVC
(MH) . . . . . . . . . 1.20 . . . . . . . . . 0.81
D
RIVER RADIATING AREA:S
D
(IN
2
) . . . . . . . . . . 81.03 . . . . . . . . 81.03
S
D
(CM
2
)......... 522.80........522.80
M
OTOR FORCE FACTOR:BL.......... 10.30.........13.90
C
OMPLIANCE VOLUME:V
AS
(FT
3
). . . . . . . . . . 2.16 . . . . . . . . . 2.11
V
AS
(LITERS) . . . . . . .6 1 .20 . . . . . . . . 59.70
S
USPENSION COMPLIANCE:C
MS
(µM/N)......160.00........160.00
M
OVING MASS,AIR LOAD:M
MS
(GRAMS)...... 155.10....... 154.90
F
REE-AIR RESONANCE:F
S
(HZ) . . . . . . . . . . 31.90 . . . . . . . . 32.40
M
ECHANICAL Q: Q
MS
. . . . . . . . . . . . . . 4.64 . . . . . . . . . 3.02
E
LECTRICAL Q: Q
ES
. . . . . . . . . . . . . . 0.59. . . . . . . . . . 0.72
T
OTAL Q: Q
TS
. . . . . . . . . . . . . . 0.52. . . . . . . . . . 0.58
M
AGNETIC-GAP HEIGHT:H
AG
(IN) . . . . . . . . . . . 0.24. . . . . . . . . . 0.24
H
AG
(MM) . . . . . . . . . . 6.00. . . . . . . . . . 6.00
V
OICE-COIL HEIGHT:H
VC
(IN)...........1.12 . .. ...... 1.12
H
VC
(MM) . . . . . . . . . 28.50 . . . . . . . . 28.50
M
AXIMUM EXCURSION:X
MAX
(IN) . . . . . . . . . . 0.40 . . . . . . . . . 0.40
X
MAX
(MM) . . . . . . . . 10.25 . . . . . . . . .10.25
(T
M
)
2.Insert wires
into connector
openings
mounting depth
5-5/8" (142mm)
cutout diameter
9" (228mm)
outer diameter
10-3/4" (272mm)
mounting height
11/16" (17 mm)
mounting depth
6-1/2" (165mm)
cutout diameter
11-1/4" (285mm)
outer diameter
12-15/16" (328mm)
mounting height
11/16" (17 mm)
Port
f
B
= 30.0Hz
The wider terminal is the positive and the
narrower is negative (also indicated on the
terminal cover).
NOTE: If using untinned bare wire, be sure
that no stray “+” and “–” strands touch
each other. Touching strands can cause a
short circuit, which can damage your
amplifier.
IMPEDANCE:IMPEDANCE:
