19
Appendix A: Target Performance Specications
Performance
CSA 1300Z CSA 2300Z
Rated Power into 4 Ω or 8 Ω;
1kHz, ≤ 0.5% THD
300W 300W
Number of Output Channels
1 2
Insertion Loss (70V & 100V
outputs)
1 dB maximum
Input Sensitivity (8 Ω Load)
Balanced line input: 775mV
RMS
; RCA Mono Sum input: 300mV
RMS
Frequency Response
(8Ω, 20Hz - 20kHz, tone controls
set to at response)
+/- 1.0 dB
Total Harmonic Distortion (THD)
(@ Full rated power, 20Hz-20kHz)
<0.5%
Signal-to-Noise Ratio (Ref. rated
output, 22KHz BW, A-weighted)
>97dB
Input Impedance (nominal)
Euro Block: 20 kΩ (balanced); RCA: 10 kΩ
Maximum Input Level
+22dBu (Norminal)
Crosstalk (Ref. rated power,
A-weighted, 1kHz)
<-70 dB
Tone Controls (Bass and Treble
non-detented potentiometers on
each channel)
Bass +/-12dB @100Hz
Treble +/-12dB @10kHz
Nominal AC Line Voltages
100V, 120V, 220V, 230-240V, 50/60 Hz
Minimum Load Impedance
Low-Z Output
70V Output
100V Output
4 Ω
12 Ω
24 Ω
4 Ω
12 Ω
24 Ω
Operating Temperature/Humidity
0°C to 35°C @ 95% R.H. (non-condensing)
Storage Temperature
-20°C to 85°C
Dimensions & Weight
Net Weight (preliminary estimate)
13.1 lb
(5.95 kg)
17.8 lb
(8.05 kg)
Dimensions
Width: 17.0 in. (432 mm)
Depth: 10.8 in. (274 mm)
Height: 3.5 in. (89 mm)
Shipping Weight
16.4 lb
(7.45 kg)
20.6 lb
(9.35 kg)
Note: For AC power draw and thermal dissipation information, please visit our website. www.jblcommercialproducts.com
