JBL Pulse spare parts
Ref.NO. Part Name_English Part .NO Description QTY per
Corresponding PCBA P/N
1 Grille MM-HM08000100-B
SPCC T=0.6mm,BLACK PAINTED 1.0
2 Lens MP-HM08A00300-B
ABS (MILK WHITE) 1.0
3 Nonwovens MC-HM08000100-B
70g(Fabric KL180MB) 212*137.5）(212*137.5） 1.0
4 Double side tape AA-PD00400100-B
S-512,W=4mm，25m 0.0
5 Back support MR-HM08S00301-B
SILICON RUBBER ,MATTE WITH PRINT（3M9448) 1.0
6 Wind-screen MC-HM08000600-B
28mm*11mm*0.1mm 180 1.0
7 Port_A MP-HM08A00400-B
ABS757 (BLACK) 1.0
8 Port_B MP-HM08A00500-B
ABS757 (BLACK) 1.0
9
LED Indicate PCBA FG-HM08GN0700-B PCBA LED Indicate 1.0
10 USB PCBA FG-HM08GN0200-B
PCBA USB 1.0
11 AUX Pcba FG-HM08GN0300-B
PCBA AUX 1.0
12 Screw MS-GEPBAPC099-B
ST2.0X7,D=3.2,Cr3+ 1.0
13 Rear house MP-HM08A00200-B
ABS757(BLACK) 1.0
14 Battery EU-BT00003600-B
3.7V/4000mAh 1.0
15 Rubber Button MR-HM08000200-B
φ54.9±0.1mm,3M9448) 1.0
16 Key PCBA
FG-HM08GN0600-B
PCBA Key
1.0
17 Double side tape MC-HM08000300-B
3M(9448)Φ52MM 1.0
18 Top cover MP-HM08C00100-B
ABS757 (WHITE),TPE( BLK),logo 1.0
19 Bottom cover MP-HM08C00200-B
ABS757 (WHITE),TPE( BLK) 1.0
20 Rubber Button MR-HM08000100-B
φ54.6±0.1mm,SILICON RUBBER (MATTE BLACK)
（
3M9448) 1.0
21 Rubber Block MR-HM08000400-B
SILICON RUBBER 11.8*8.04mm BLACK 60 1.0
22 Baffle MP-HM08A00100-B
ABS757(BLACK) 1.0
23 Screw MS-GEPBAPC0A5-B
ST2.6x7,Cr3+ 13.0
24 Screw MS-GEWBAPC034-B
ST2.0*7
，
W=Φ5.0MM, Cr3+ 3.0
25 Screw MS-GEPBAPC0A5-B
ST2.6x7,Cr3+ 13.0
26 Driver EB-M04000080300-B
Dimention: 40mm;Rated impedance: 8 Ohm;SPL: 80dB at 200,400,600,800;FO: 170Hz+/-20% 2.0
27 Main PCBA FG-HM08GN0400-B PCBA Main
1.0
28 LED Bar PCBA FG-HM08GN0500-B PCBA LED Bar
8.0
29 Double side tape MC-HM08000200-B
3M(9448)149.6MM*4.8MM 8.0
30 Connect cable driver EW-MC01205100-B
AWG#24,4,L=120MM 1.0
31 EVA MF-HM08000400-B
426*3.5*0.5mm 1.0
32 FFC cable EW-MC01151700-B
14P,L=115mm 4.0
33 FFC cable EW-MC01508000-B
14P,L=150mm 4.0
34 FFC cable EW-MC01550100-B
10P,L=155mm 1.0
35 EVA Bluetooth antenna MF-HM08000900-B
43x6.5x2mm 1.0
36 Antenna bluetooth EU-EL00000100-B
PCB 1.0
37 Mainboard EVA MF-HM08000201-B
12MM*4MM*1MM 2.0
38 Aux Socket EVA MF-HM08000500-B
12.0*8.0*2.0mm 1.0
39 Battery EVA bottom MF-HM08000701-B
2.0mm（20mm*20mm） 2.0
40 Battery EVA top MF-HM08000600-B
12*12*4mm 1.0
41 FFC cable EW-MC01701100-B
7P,L=170mm 1.0
42 FFC cable EVA MF-HM08000100-B
30*20*1.0mm 1.0
43 Port EVA MF-HM08000300-B
55*20*0.5mm 2.0
Packing
4 USB cable EW-MA10001000-B
L=1000mm,OD=4.5mm, MicroUSB to USB charger 1.0
5 Adaptor ET-A240V0A100-B
Switching AC/DC adapter, input:AC 100V-240V, output:USB DC 5V/2.3A,-Black 1.0
5a EU plug EG-000000DB00-B
5b GB plug EG-000000DA00-B
15 Master carton PC-HM08000100-B
219x215x183mm 0.5
