Harman JBL TUNE760 NC User Manual

TECH
SPEC
Model: TUNE760NC
Driver size: 40 mm Dynamic Driver
Power supply: 5 V
1 A
Weight: 220 g / 0.485 lbs
Headset battery type: Polymer Li-ion battery (610 mAh / 3.7 V)
Charging time: < 2 hrs from empty
Music play time with BT on and ANC on: 35 hrs
Music play time with BT on and ANC off: 50 hrs
Frequency response: 20 Hz - 20 kHz
Impedance: 32 ohm
Sensitivity passive mode: 103 dB SPL/1 mW
Sensitivity active mode: 95 dB SPL/1 mW
Maximum SPL: 95 dB
Microphone sensitivity: -30 dBV/Pa
Bluetooth version: 5.0
Bluetooth profile version: A2DP 1.3, AVRCP 1.5, HFP 1.6
Bluetooth transmitter frequency range: 2.4 GHz - 2.4835 GHz
Bluetooth transmitted power: < 10 dBm
Bluetooth transmitted modulation: GFSK, π/4 DQPSK , 8DPSK
Maximum operation temperature: 45 °C

Harman JBL TUNE760 NC Specifications

Battery

battery capacity	610 mAh
charging time	<2 hrs
music play time with BT on and ANC on	35 hrs
music play time with BT on and ANC off	50 hrs

Audio Specifications

frequency response	20Hz – 20kHz
impedance	32 ohm
sensitivity passive mode	103 dB SPL/1mW
sensitivity active mode	95 dB SPL/1mW
maximum SPL	95 dB
microphone sensitivity	-30 dBV/Pa

Bluetooth Specifications

bluetooth version	5.0
bluetooth profile version	A2DP 1.3, AVRCP 1.5, HFP 1.6
bluetooth transmitter frequency range	2.4GHz – 2.4835GHz
bluetooth transmitted power	<10 dBm
bluetooth transmitted modulation	GFSK, π/4 DQPSK, 8DPSK

Power

power supply	5V 1A
maximum operation temperature	45°C

Weight and Dimensions

weight	220 g
driver size	40 mm
cable length	1.2 m
