Page #13 background imageLoading...
Page #13 background image
9 – English
OPERATION
WARNING:
Make sure the latch on the battery pack snaps in place
and the battery pack is fully seated and secure in the
trimmer battery port before beginning operation. Failure
to securely seat the battery pack could cause the battery
pack to fall out, resulting in serious personal injury.
INSTALLING/REMOVING THE BATTERY PACK
See Figure 5.
Slidepowerselectiondooroverpowerreceptacleuntil
it clicks into place.
Insert the battery pack into the product as shown.
Make sure the latch on the battery pack snaps into
place and the battery pack is secured before beginning
operation.
Depressthelatchandpulltoremovethebatterypack.
For complete charging instructions, see the operator’s
manuals for your battery pack and charger.
STARTING/STOPPING THE TRIMMER (DC)
See Figures 5 - 6.
To start:
Slidepowerselectiondooroverpowerreceptacleuntil
it clicks into place.
Insert battery.
Pressandholdthelock-out.
Depress the switch trigger.
To stop:
Release the switch trigger to stop the motor.
Upon release of the switch trigger, the lock-out will
automatically reset to the locked position.
STARTING/STOPPING THE TRIMMER (AC)
See Figures 6 - 8.
To start:
Removebatterypackfromtrimmerifinstalled.
Slidepowerselectiondooroverbatteryportuntilitclicks
into place.
Route an extension cord loop through the opening behind
the rear handle and wrap around the cord retainer.
NOTICE:
Always use cord retainer to properly attach extension
cord to string trimmer. Failure to use cord retainer may
resultindamagetostringtrimmerand/orextensioncord.
Attach the outlet end of the extension cord to the plug
on the rear of the string trimmer.
NOTE: Useonlyapprovedoutdoorextensioncords.
Pressandholdthelock-out.
Depress the switch trigger.
To stop:
Release the switch trigger to stop the motor.
Upon release of the switch trigger, the lock-out will
automatically reset to the locked position.
TELESCOPING SHAFT
See Figure 9.
The shaft can be extended or shortened for ease of use.
Remove the battery pack or disconnect from power
supply.
Loosen the telescoping shaft coupler by turning it coun-
terclockwise. Slide the shaft to the desired position.
Tighten the coupler by turning clockwise. Make sure the
shaft is securely tightened before reinstalling the battery
pack or reconnecting to the power source.
OPERATING THE TRIMMER
See Figure 10.
Hold the trimmer with your right hand on the rear handle
and your left hand on the front handle.
Keep a firm grip with both hands while in operation.
Trimmer should be held at a comfortable position with
the rear handle about hip height.
Cuttallgrassfromthetopdown.Thiswillpreventgrass
from wrapping around the boom housing and string head
whichmaycausedamagefromoverheating.
If grass becomes wrapped around the string head:
Remove the battery pack or disconnect from power
supply.
Removethegrass.
WARNING:
Always hold the string trimmer away from the body
keeping clearance between the body and the string
trimmer. Any contact with the string trimmer cutting head
while operating can result in serious personal injury.
CUTTING TIPS
See Figure 11.
Keep the trimmer tilted toward the area being cut; this
is the best cutting area.
The string trimmer cuts when passing the unit from right
toleft.Thiswillavoidthrowingdebrisattheoperator.
Avoidcuttinginthedangerousareashowninfigure11.
Use the tip of the line to do the cutting; do not force string
head into uncut grass.
