Operation and use 1B20, 1B30, 1B40, 1B50
54
HATZ
Manual
Overview
Water in the fuel tank collects at the lowest point of the fuel tank in the water
separator.
Standard Model with window
1 Drain screw, hex (standard)
2 Window (additional equipment)
3 Drain screw (manually operated)
Procedure
Step Activity
1 Model with window:
Check the window (2) for water content.
Collected water can be clearly identified by the noticeable sepa-
rating line between the water and the diesel fuel above it.
2 Place a suitable container under the drain screw (1) or (3).
NOTE: In inaccessible locations, an extension hose can be
mounted on the drain screw (3).
3 Open the drain screw (1) or (3) and drain the water into the con-
tainer.
4 When fuel emerges, close the drain screw.
5 Dispose of the water/fuel mixture in accordance with the local
environmental regulations.
