DIMENSIONS
MODEL A
in/mm
A'
in/mm
B
in/mm
C
in/mm
D
in/mm
E
in/mm
F
in/mm
G*
in/mm
H
in/mm
J*
in/mm
K*
in/mm
L
WEIGHT
lbs/kg
HRSN5A 20.94/532 9.84/250 8.46/215 4.57/116 11.54/293 11.89/302 7.17/182 1.811/46 3.35/85
(4) M20
- 2.5 X
35mm D
F16
6.50/165
11.42 /
290
36.5
turns
90°
167/76
HRSN5B 20.94/532 9.84/250 8.46/215 4.57/116 11.54/293 11.89/302 7.17/182 1.811/46 3.35/85
(4) M20
- 2.5 X
35mm D
F16
6.50/165
11.42 /
290
36.5
turns
90°
167/76
HRSN6A 20.94/532 9.84/250 8.46/215 4.57/116 11.54/293 11.89/302 7.17/182 1.811/46 3.35/85
(4) M20
- 2.5 X
35mm D
F16
6.50/165
11.42 /
290
36.5
turns
90°
167/76
COVER REMOVAL
CLEARANCE
OUTPUT
SHAFT CW
*Consult Hayward Flow Control for optional ISO patterns
DIMENSIONAL DATA
HRCL, HRCD 5A~6A
MECHANICAL DATA
