HIKVISION DS-2CD2120F-I User Manual

User Manual
Code: DS-2CD2120F-I(2.8mm)(DT)
IP VANDALPROOF CAMERA DS-2CD2120F-I(2.8mm)(DT) - 1080p Hikvision
DELTA-OPTI Monika Matysiak; https://www.delta.poznan.pl
POL; 60-713 Poznań; Graniczna 10
e-mail: delta-opti@delta.poznan.pl; tel: +(48) 61 864 69 60
2021-10-02 DS-2CD2120F-I(2.8mm)(DT) 3/5
ONVIF:
RS-485 interface:
Mobile phones support:
Port no.: 8000 or access by a cloud (P2P)
• Android: Free application iVMS-4500 or Hik-Connect
• iOS (iPhone): Free application iVMS-4500 or Hik-Connect
Default IP address: 192.168.1.64
Default admin user / password: admin / -
Web browser access ports: 80
PC client access ports: Port no.: 8000 or access by a cloud (P2P) - iVMS-4200 application
Mobile client access ports: 8000
Port ONVIF: 80
RTSP URL:
• Main stream
rtsp://192.168.1.64:554/Streaming/Channels/101/ - RTSP - without authorization
rtsp://user:password@192.168.1.64:554/Streaming/Channels/101/ - with
authorization
• Sub stream
rtsp://192.168.1.64:554/Streaming/Channels/102/ - RTSP - without authorization
rtsp://user:password@192.168.1.64:554/Streaming/Channels/102/ - with
authorization
Main features:
• Possibility to change the resolution, quality and bit rate
• Configurable: brightness, contrast, saturation
• Day/night mode
• ICR - Movable InfraRed filter
• 3D-DNR - Digital Noise Reduction
• D-WDR - Wide Dynamic Range
• BLC - configurable Back Light Compensation
• Motion Detection
• Intelligent Image Analysis - detection line violation and intrusion in an area
previously designated
• Tamper signaling
• ANR - Automatic Network Replenishment allows to save image to the card when the
network connection with DVR is break (network failure) and next synchronize its
Vandal-proof:
Power supply:
• PoE (802.3af)
• 12 V DC / 310 mA
Housing: Dome - Metal
Color: White
"Index of Protection": IP66
Operation temp: -30 °C ... 60 °C
Weight: 0.385 kg
Dimensions: Ø 111 x 82 mm
Supported languages: Chinese Simplified, English
Manufacturer / Brand: Hikvision
Country of origin: China
Guarantee:
3 years

HIKVISION DS-2CD2120F-I Specifications

General

Fixed focal length	4 mm
Maximum aperture number	2
Pan range	0 - 355 °
Tilt angle range	0 - 75 °
Angle of rotation	355 °
Camera shutter speed	1/3 - 1/100000 s
Minimum illumination	0 lx
Field of view (FOV) angle	85 °
Type	IP security camera
Placement supported	Outdoor
Connectivity technology	Wired
Wide Dynamic Range (WDR)	Yes
Form factor	Dome
Mounting type	Ceiling
Product color	White
Protection features	Splash proof
Total megapixels	2 MP
Maximum resolution	1920 x 1080 pixels
Supported video modes	720p, 1080p
Image quality adjustment	Brightness, Contrast, Saturation
Video compression formats	H.264, M-JPEG
Supported graphics resolutions	1280 x 720 (HD 720), 1280 x 960
Sensor type	CMOS
Optical sensor size	1/2.8 \
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	128 GB
LED type	IR
Night vision distance	30 m
Cabling technology	10/100Base-T(X)
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
Number of cameras	1
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 95 %
DC output voltage	12
Power source type	PoE
Power consumption (max)	5 W
Interface	RJ-45

Weight and Dimensions

Height	82 mm
Weight	500 g
Diameter	111 mm
