Code: DS-2CD2386G2-I(2.8MM)
IP CAMERA DS-2CD2386G2-I(2.8MM) ACUSENSE - 8.3 Mpx Hikvision
DELTA-OPTI Monika Matysiak; https://www.delta.poznan.pl
POL; 60-713 Poznań; Graniczna 10
e-mail: delta-opti@delta.poznan.pl; tel: +(48) 61 864 69 60
2021-06-07 DS-2CD2386G2-I(2.8MM) 2/6
IP camera with efficient H.264/H.265 image compression
algorithm for clear and smooth video streaming at maximal
resolution of 3840 x 2160 (8.3 MPx).
PoE powering possibility, compatible with the 802.3af standard
makes the device more universal and easier to install.
Powered by Darkfighter - the camera has very good sensitivity,
dedicated to poor lighting conditions. Camera is according to IP67
Index of Protection norm.
Standard: TCP/IP
Sensor: 1/2 " Progressive Scan CMOS
Matrix size: 8.3 Mpx
Scanning system: Progressive
Resolution:
3840 x 2160 - 8.3 Mpx ,
3072 x 1728 - 5.3 Mpx ,
2688 x 1520 - 4 Mpx ,
1920 x 1080 - 1080p ,
1280 x 720 - 720p
Lens: 2.8 mm
View angle:
• 111 ° (manufacturer data)
• 106 ° (our tests result)
Range of IR illumination: 30 m
RS-485 interface:
Memory card slot: Micro SD memory cards up to 256GB support (possible local recording)
Image compression method: H.265+ / H.265 / H.264+ / H.264 / MJPEG
Alarm inputs / outputs:
Audio:
Bitrate: 32 kb/s ... 16384 kb/s
Main stream frame rate: 20 fps @ 8.3 Mpx

HIKVISION DS-2CD2386G2-I Specifications

General

Form factor	Turret
Mounting type	Ceiling/wall
Product color	White
Housing material	Metal
Protection features	Dust resistant, Water resistant
International Protection (IP) code	IP67
Type	IP security camera
Certification	FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); KC (KN 32: 2015, KN 35: 2015) UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013) CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Languages support	Multi
Number of languages	33
Placement supported	Indoor & outdoor
Connectivity technology	Wired
Wide Dynamic Range (WDR)	Yes
Sensor type	CMOS
Number of sensors	1
Optical sensor size	1/1.8 \
Fixed focal length	2.8 mm
Detect distance (wide)	89.2 m
Maximum aperture number	1.6
Observe distance (wide)	35.4 m
Identify distance (wide)	8.9 m
Recognize distance (wide)	17.8 m
LED type	IR
Infra-red wavelength	850 nm
Night vision distance	30 m
Pan range	0 - 360 °
Tilt angle range	0 - 75 °
Angle of rotation	360 °
Camera shutter speed	1/3 - 1/100000 s
Minimum illumination	0 lx
Bit rate control	Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Total megapixels	8 MP
Gain control type	Auto
Maximum resolution	3840 x 2160 pixels
Image quality adjustment	Brightness, Contrast, Saturation, Sharpness
Video compression formats	H.264, H.264+, H.265, H.265+, M-JPEG
Noise reduction technology	3D noise reduction
Supported graphics resolutions	640 x 360, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1200 (WUXGA), 2688 x 1520, 3200 x 1800, 3840 x 2160
Wi-Fi	No
Number of users	32 user(s)
Networking standards	IEEE 802.3af
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	256 GB
Security algorithms	TLS
Intelligent Video Surveillance (IVS) system features	Face detection, Scene change
Behavior analysis	Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection
DC output current	0.48 A
DC output voltage	12
Power source type	DC, PoE
Power consumption (max)	5.8 W
Power consumption (Power over Ethernet (PoE))	6.8 W
Storage temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 95 %
Signal-to-Noise Ratio (SNR)	52 dB

Weight and Dimensions

Length	126.3 mm
Weight	740 g
Diameter	138.3 mm
Package width	170 mm
Package height	150 mm
Package weight	1020 g
