User Manual
Code: DS-2CD2386G2-ISU/SL(2.8MM)
IP CAMERA DS-2CD2386G2-ISU/SL(2.8MM) ACUSENSE - 8.3 Mpx Hikvision
DELTA-OPTI Monika Matysiak; https://www.delta.poznan.pl
POL; 60-713 Poznań; Graniczna 10
e-mail: delta-opti@delta.poznan.pl; tel: +(48) 61 864 69 60
2021-11-04 DS-2CD2386G2-ISU/SL(2.8MM) 2/6
IP camera with efficient H.264/H.265 image compression
algorithm for clear and smooth video streaming at maximal
resolution of 3840 x 2160 (8.3 MPx).
PoE powering possibility, compatible with the 802.3af standard
makes the device more universal and easier to install.
Powered by Darkfighter - the camera has very good sensitivity,
dedicated to poor lighting conditions. Camera is according to
IP67 Index of Protection norm.
Standard: TCP/IP
Sensor: 1/1.8 " Progressive Scan CMOS
Matrix size: 8.3 Mpx
Scanning system: Progressive
Resolution:
3840 x 2160 - 8.3 Mpx ,
3072 x 1728 - 5.3 Mpx ,
2688 x 1520 - 4 Mpx ,
1920 x 1080 - 1080p ,
1280 x 720 - 720p
Lens: 2.8 mm
View angle:
• 111 ° (manufacturer data)
• 100 ° (our tests result)
Range of IR illumination: 30 m
RS-485 interface:
Memory card slot: Micro SD memory cards up to 256GB support (possible local recording)
Image compression method: H.265+ / H.265 / H.264+ / H.264 / MJPEG
Alarm inputs / outputs: 1 / 1
