HIKVISION DS-2CD3021G0-I User Manual

Network Bullet Camera·Quick Start Guide
14
And you can take steps of ceiling mounting as a reference for wall
mounting.
Steps:
1. Paste the drill template (supplied) to the desired mounting
position on the ceiling.
2. Drill the screw holes in the ceiling according to the supplied drill
template.
Note:
Drill the cable hole, if adopting ceiling outlet to route the cable.
3-Φ 4 mm
Drill Template
Cable
Hole
Side
Opening
Screw
Hole
Figure 2-1 The Drill Template
3. Route the cables through the cable hole (optional), or the side
opening.
4. Fix the camera on the ceiling with supplied screws.
