General| UN number | - |
|---|---|
| Front camera | No |
| RS-485 ports | 1 |
| Type | Basic access control reader |
| Certification | FCC, CE |
| Product color | Black, Grey |
| LED indicators | Status |
| RFID frequency | 13.56 MHz |
| Housing material | Acrylonitrile butadiene styrene (ABS), Polycarbonate (PC) |
| Access code reader | Yes |
| Authentication type | Access chip/card |
| Keypad number of keys | 12 |
| Access chip/card reader type | Contactless |
| Contactless working distance | 50 mm |
| International Protection (IP) code | IP64 |
| Operating temperature (T-T) | -20 - 65 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
| Input voltage | 12 V |
| Power consumption | 500 mA |
| Power consumption (typical) | 2 W |
Weight and Dimensions| Depth | 14.7 mm |
|---|---|
| Width | 76 mm |
| Height | 129 mm |
| Weight | 150 g |
