Video Door Phone User Manual
12
Hooks
Slots
Wall Mounting
Shield Panel
Door Station
Rear Panel
Figure 4-6 Hooking the Door Station to the Shield
3. Secure the door station with the mounting shield with the set screw.
Set Screw
Figure 4-7 Securing the Door Station
