3
Installing the Stand or Wall mount bracket
9.5 -11.5 mm
Wall mount bracket
Wall Mount Screw
Wall Mount Spacer
Rear cover of the TV
Wall mount hole pattern (mm)
100 × 200
Wall mount screw size (mm) M6
Follow instructions provided with the Wall mount bracket.
NOTES
Installing the wall mount bracket
•
The diameter and length of the screws differ depending on the wall mount bracket model.
•
Wall mount bracket is optional, your device may not have wall mount bracket, please refer
to the actual accessories.
