Si n c e 1 9 91
Breathing & Movement Monitor
5
Medically approved
User Guide
English
4
V.BS5.1.EN.6.13
• Batteries are not inserted
correctly or may be flat.
• Check batteries are inserted in the Control Unit
observing the correct polarity.
• Control Unit requires 4 X AA 1.5V Alkaline batteries (not supplied).
• Batteries low. • Replace all 4 batteries.
• Sensor pad is out of order.
• Cable is connected to
monitor’s blocked socket.
• Connect one sensor pad lay the baby on the bed for 1 minute.
If the alarm does not activate, the sensor pad is in order. If the
alarm activates, disconnect and place the sensor pad aside.
• Connect the other sensor pad and repeat steps above.
• Do not connect any cables to the blocked socket (only to
“SENSOR” socket).
• The mattress is not
touching the sensor pads.
• Make sure that the mattress and the sensor pads
are touching.
• The mattress is raised
(there is an object near the
sensor pads).
• Make sure that there are no objects next to the sensor pads
• Placing two sensors next to
each other (or using one
sensor) when the baby is of
crawling age or using two
sensor pads far apart from
each other when baby is
young and is not crawling yet.
• Connect according to instructions.
• It is important to use only one sensor pad when the baby is young
and is not crawling yet.
• It is important to make sure that two sensor pads are used when the baby
is moving around.
• Make sure the sensors are placed underneath baby’s location in bed/crib.
• The mattress does not
enable transfer of baby
movements. (a rigid mattress,
a mattress with springs or a
mattress with air pockets).
• Place extra plywood under the sensor pad so that the
sensor pad and the mattress will be tightly pressed together.
• Performance test is not
correct.
• Do not conduct performance test by picking up the
baby out of bed and waiting for the alarm to sound.
Kindly conduct performance test according to guidance in page 3.
• Environmental influences
detected by the sensor
pads, such as wind, fan, air
conditioner, mobile,
vibrations.
• Perform a test which will detect the source of the movement
that the device detects. For example, sources of wind such as: air
conditioner, an open window or a fan; movements of a baby
mobile (which can vibrate even if it's not turned on) walking
around the bed area or an intercom placed near the bed with
intense transmission levels. Solutions: Eliminate sources of wind,
remove the mobile etc. After neutralizing all environmental
influences, perform the test again. If even after neutralizing all of
the environmental influences, the alarm does not go off within
20 seconds, perform the following:
1. In the back of the sensor pads (see illustration 1)
reduce the sensitivity level to position 2 (on both sensor pads) and
perform again the Performance Test. If the alarm sounds within 20
seconds, than keep this sensitivity level.
2. If the alarm does not go off in time, than reduce the sensitivity
level to position 1 and perform again the Performance Test. If the
alarm sounds within 20 seconds, than keep this sensitivity level.
3. If the alarm does not go off in time at this level, than it is
suggested using only one sensor pad with the sensitivity level
adjusted on position 1.
4. PAY ATTENTION: Should false alarms sound as a result of
reduced sensitivity, than increase the level of sensitivity and
perform the Performance Test.
Solution
Possible Cause
Symptom
Lights on Control
Unit don’t illuminate
when turned ON
Low battery voltage
warning (red light)
on the Control Unit
False alarm up to
1/2 minute from
activating
False alarm after 1/2
minute from
activating
Delayed alarms
while taking the
baby out of the bed
The alarm does
not go off within
20 seconds when
performing the
correct
performance test
Troubleshooting Guide
5
For all product related questions kindly contact your nearest distributor,
which can be found at www.hisense.co.il
Made by Hisense Ltd.
ISO 9001:2008 and ISO 13485:2003 certified
23, Becker St. Rishon le Zion 7535929, Israel
www.hisense.co.il
European Authorized Representative
OBELIS s.a email@obelis.net
Boulevard Général Wahis 531030 Brussels, Belgium
Tel +(32) 2.732.59.54 Fax +(32) 2.732.60.03
Powered by 4 size AA, 1.5 volt batteries.
Power consumption approx. 1mA.
Battery life approx. 6 months using alkaline batteries.
Alarm volume typically 85dB SPL at distance of
one meter.
Size of sensor pad is 216 mm.
Technical Specifications
Contents
• Control Unit
• Control Unit Holder
• Optional hanging hook
• 2 Sensor pads
• 2 Cable Ties
• User guide
Please note that the batteries are not supplied.
"Babysense" requires no special treatment beyond
replacing batteries when the battery indicator light
goes on. The sensor pads and control unit may be
wiped with a damp cloth.
Batteries should be removed and the device stored in
a dry shaded place when not in use.
Caring for your babysense
It is recommended to replace sensors
every two years
