Installing a Wall-Mount Bracket
If you want to attach the TV to a Wall-Mount bracket (not provided), you should first remove the stand if it is pre-attached (see
Step 1).
1. Make sure the TV is laid face-down on a clean, safe,
and cushioned space, remove the original screws in the
bracket holes on the TV back over.
3. Follow instructions provided with the Wall-Mount bracket.
If you are not sure of your ability to do complete the installation, contact a professional installer or service technician for
assistance. The manufacturer is not responsible for any damages or injuries that occur due to mishandling or incorrect
assembly.
The selected screws are 10.5 ~ 11.5 mm in length when measured from the attaching surface of the TV's rear cover.
The diameter and length of the screws differ depending on the Wall-Mount Bracket model.
tekcarb gnidnopserroc eht ni srecaps dedivorp eht ecalP.2
holes. Attach purchased bracket (1.5 ~ 2.5 mm thickness)
on the TV with 4 screws (M6 × L45
) which in accessories
bag. Follow instructions provided with the wall bracket.
1
WARNING
Use only the 4 screws (M6 × L45) provided with the TV to prevent internal damage to the TV set or cause it to fall.
2
3. Align the stand cover with the stand column, then secure the stand column to the stand cover with the four provided
Screws A. See Figure 3.
4. Align the stand cover with the screw holes on the bottom of TV back, secure the stand to the TV with the four provided
Screws A. See Figure 4.
NOTE
Illustrations are for your reference only!
Screw B (M6 × L45)
Spacer × 4
Bracket
(1.5~2.5mm)
To Next Page
