FUNCTIONAL DESCRIPTION
NOTE:
The information contained in this Instruction Manual is designed to assist you in the
safe operation and maintenance of the power tool.
NEVER operate, or attempt any maintenance on the tool unless you have first read and
understood all safety instructions contained in this manual.
Some illustrations in this Instruction Manual may show details or attachments that differ
from those on your own power tool
NAME OF PARTS
Fig. 1
SPECIFICATIONS
Motor Single Phase, Series Commutator Motor
Power Source
Single Phase 120V AC 60 Hz
Current 6.0A
No-Load Speed 0-2500/min.
Drill Chuck Capacity 3/8" (10mm)
Capacity Steel Twist Bit 3/8"(10mm)
Wood Flat Spade Bit 1"(25mm)
Auger Bit 5/8"(16mm)
Weight (without cord) 3.1 lbs(1.4kg)
Gear Cover
Housing
Drill Chuck
Nameplate
Push Button
Stopper
Switch Trigger
Speed Control Dial
Handle Cover
