English
22
If nails are driven too shallow, turn the adjuster to
the deep side.
3 Stop turning the adjuster when a suitable
position is reached for a nailing test.
4 Connect the air hose.
ALWAYS WEAR SAFETY GLASSES.
Perform a nailing test.
5 DISCONNECT AIR HOSE FROM NAILER.
6 Choose a suitable position for the adjuster.
USING THE BLOW NOZZLE
WARNING
● Be sure to release your finger from the trigger before using the
blow nozzle.
● Do not point the air outlet at a person.
● Do not use the blow nozzle with the push lever left fit.
This Nailer has a blow nozzle that blows out wood
shavings which occur during work.
Press the knob with your thumb to use the blow nozzle,
as shown in the figure.
NOTE:
● When the blow nozzle is used for a long time, the
nailing force may degrade temporarily. In this case,
allows the air supply pressure to stabilize before
starting work.
● Oil in the body or drained water from the compressor
can sometimes spout out of the air outlet. It is
recommended that you once conduct a test before
use and see if such phenomenon happens at an
environment where spouted oil will cause any
inconvenience.
Too Deep
Too Shallow
Turn Adjuster
Turn Adjuster
Flush
Flush
2
2
Knob
air outlet
To Next Page
