Split system - Indoor unit
YUTAKI S
Model Power supply
Applicable voltage
Operation mode
MC
(A)
CB
(A)
ELB
(nº of poles/A/mA)
U max.
(V)
U min.
(V)
RWM-(2.0-3.0)NRE(-W) 1~ 230V 50Hz 253 207
Without electric heaters 0.2 5
2/40/30
With electric heater 14.6 16
With DHW tank heater
14.6
16
With electric and DHW tank heaters 28.9 32
RWM-(4.0-6.0)NE(-W)
1~ 230V 50Hz 253 207
Without electric heaters 0.3 5
2/40/30With electric heater 29.0 32
With DHW tank heater 14.7 16
With electric and DHW tank heaters 43.4 50 2/63/30
3N~ 400V 50Hz 440 360
Without electric heaters 0.3 5
4/40/30
With electric heater 9.9 15
With DHW tank heater 14.7 15
With electric and DHW tank heaters 24.2 25
RWM-(8.0/10.0)NE(-W) 3N~ 400V 50Hz 440 360
Without electric heaters 0.6 5
4/40/30
With electric heater 14.9 20
With DHW tank heater 15.0 15
With electric and DHW tank heaters 29.2 30
? NOTE
The data corresponding to DHW tank heater is calculated in combination with the domestic hot water tank accessory “DHWT-(200/300)S-3.0H2E”.
YUTAKI S COMBI
Model Power supply
Applicable voltage
Operation mode
MC
(A)
CB
(A)
ELB
(nº of poles/A/mA)
U max.
(V)
U min.
(V)
RWD-(2.0-3.0)NRW(S)
E-(200/260)(-K)(-W)
1~ 230V 50Hz 253 207
Without electric heaters 0.2
5
2/40/30
With electric heater 14.6
16
With DHW tank heater 12.7
16
With electric and DHW tank heaters 27.1
32
RWD-(4.0-6.0)NW(S)
E-(200/260)S(-K)(-W)
1~ 230V 50Hz 253 207
Without electric heaters 0.3 5
2/40/30With electric heater 29.0 32
With DHW tank heater 12.8 16
With electric and DHW tank heaters 41.5 50 2/63/30
3N~ 400V 50Hz 440 360
Without electric heaters 0.3 5
4/40/30
With electric heater 9.9 15
With DHW tank heater 12.8 15
With electric and DHW tank heaters 22.4 25
ELECTRICAL AND CONTROL SETTINGS
PMML0510 rev.1 - 10/2019
54
