Honda CBR1000RR User Manual

Engine Will Not Start......................................P. 179
Overheating (High coolant temperature
indicator is on).............................................
..P. 180
Warning Indicators On or Flashing.............P. 181
Low Oil Pressure Indicator .............................. P. 181
PGM-FI (Programmed Fuel Injection)
Malfunction Indicator Lamp (MIL)............... P. 181
ABS (Anti-lock Brake System) Indicator....... P. 182
HESD (Honda Electronic Steering Damper)
Indicator ............................................................ P. 182
Torque Control Indicator................................. P. 183
Tire Puncture.................................................... P. 184
Electrical Trouble............................................. P. 193
Battery Goes Dead............................................ P. 193
Burned-out Light Bulb ..................................... P. 194
Blown Fuse..........................................................P. 197
20170830152249_31MKF6100_enu_BOOK Page 181 Wednesday, August 30 2017 15:45:50 JST
Troubleshooting

Honda CBR1000RR Specifications

General

Engine Type	Liquid-cooled 4-stroke 16-valve DOHC inline-4
Displacement	999cc
Compression Ratio	13.0:1
Transmission	6-speed
Ignition	Computer-controlled digital transistorized with electronic advance
Bore x Stroke	76 mm x 55.1 mm
Fuel System	PGM-DSFI (Programmed Dual Sequential Fuel Injection)
Front Suspension	43 mm inverted telescopic fork with Big Piston Front Fork (BPF), spring preload, rebound and compression damping adjustability
Rear Suspension	Unit Pro-Link with gas-charged HMAS damper, spring preload and rebound damping adjustability
Front Brakes	Dual 320 mm hydraulic discs with radial-mount 4-piston calipers
Rear Brakes	Single 220 mm hydraulic disc with single-piston caliper
Front Tire	120/70ZR-17
Rear Tire	190/50ZR-17
Wheelbase	1, 405 mm (55.3 in)
Max Power	189 hp @ 13, 000 rpm
Max Torque	114 Nm @ 11, 000 rpm
