Honda CH250 ELITE250 User Manual

TRANSPORTING THE SCOOTER
(1 ) Drain screw
-
* To prevent the possibility of a fire or
explosion when transporting the
sco-
oter always:
- Drain the fuel tank and carburetor.
- Carry the scooter upright in its normal
riding position to prevent oil and bat-
tery electrolyte from leaking.
- Tie down the scooter at the wheels.
62
Draining Fuel
Perform this operation only in a well-
ventilated area.
Gasoline is flammable and explosive
under certain conditions. Always stop
the engine, and do not smoke or allow
frames or sparks in the area when
draining or refueling.
Stop the engine and remove the center
cover.
Empty the fuel tank using a commer-
cially available hand siphon or other
equivalent way.
Place the free end of the carburetor
drain tube into a suitable fuel contain-
er.
Open the carburetor drain by turning
the drain screw counterclockwise.
When all fuel has drained, turn the
screw clockwise until tight.

Honda CH250 ELITE250 Specifications

General

Engine Type	4-stroke, single-cylinder
Displacement	244 cc
Bore x Stroke	72.0 mm x 60.0 mm
Compression Ratio	10.0:1
Fuel System	Carburetor
Ignition	CDI
Starter	Electric
Transmission	Automatic V-Matic
Final Drive	Belt
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Drum
Front Tire	110/90-12
Rear Tire	120/90-10
Rear Suspension	Unit swingarm with dual shock absorbers
