Adjustments for Competition 111
Front Suspension Adjustments
Both compression and rebound damping can be
increased by turning the adjuster clockwise.
Always start with full hard when adjusting
damping.
Do not turn the adjuster screw more than the
given positions or the adjuster may be damaged.
Be sure that the compression and rebound
adjusters are firmly located in a detent, and not
between positions.
NOTICE
Fork Springs
The fork springs in CRF’s are about right for
riders weighing between 170 lb (77 kg) and 200
lb (91 kg) (less riding gear). So if you're a
heavier rider, you have to go up on the oil
capacity or get a stiffer spring. Do not use less oil
than the minimum specified for each spring or
there will be a loss of rebound damping control
near full extension. If the fork is too hard on big
bumps, turn the damping adjuster
counterclockwise 1-click and lower the oil
capacity in increments of 0.2 US oz (5 cm
3
) in
both fork legs until the desired performance is
obtained. Do not, however, lower the oil capacity
below the minimum oil capacity.
Minimum oil capacity:
Standard spring:
10.0 US oz (296 cm
3
)
Softer spring: 10.2 US oz (301 cm
3
)
Stiffer spring: 10.1 US oz (299 cm
3
)
When adjusting oil capacity, bear in mind that
the air in the fork will increase in pressure while
riding; therefore, the higher the oil capacity, the
higher the eventual pressure of any air in the
fork.
(1) compression (2) rebound damping
damping adjuster screw
adjuster screw
