SPECIFICATIONS
ENGINE SPECIFICATIONS
*1: The power rating of the engine indicated in this document is the net power output tested on a production engine for the engine
model and measured in accordance with SAE J1349 at 3,600 rpm (net power) and at 2,500 rpm (max net torque). Mass production
engines may vary from this value. Actual power output for the engine installed in the final machine will vary depending on numerous
factors, including the operating speed of the engine in application, environmental conditions, maintenance, and other variables.
Model GX120UT2/T2 GX160UT2/T2 GX200UT2/T2
Description code GCBMT/GCBNT GCBPT/GCBRT GCBTT/GCBUT
Type 4 stroke, overhead valve, single cylinder, inclined by 25°
Displacement 118 cm
3
(7.2 cu–in) 163 cm
3
(9.9 cu–in) 196 cm
3
(12.0 cu–in)
Bore x stroke 66.0 x 42.0 mm
(2.60 x 1.65 in)
68.0 x 45.0 mm
(2.68 x 1.77 in)
68.0 x 54.0 mm
(2.68 x 2.13 in)
Net power (SAE J1349) *1 2.6 kW (3.5 HP)/
3,600 min
-1
(rpm)
3.6 kW (4.9 HP)/
3,600 min
-1
(rpm)
4.1 kW (5.6 HP)/
3,600 min
-1
(rpm)
Continuous rated power 2.1 kW (2.9 HP)/
3,600 min
-1
(rpm)
2.9 kW (3.9 HP)/
3,600 min
-1
(rpm)
3.7 kW (5.0 HP)/
3,600 min
-1
(rpm)
Maximum net torque
(SAE J1349) *1
7.3 N·m (0.7 kgf·m, 5.4
lbf·ft)/2,500 min
-1
(rpm)
10.3 N·m (1.1 kgf·m, 7.6
lbf·ft)/2,500 min
-1
(rpm)
12.4 N·m (1.3 kgf·m, 9
lbf·ft)/2,500 min
-1
(rpm)
Compression ratio 8.5 : 1 9.0 : 1 8.5 : 1
Fuel consumption (at
continuous rated power)
1.0 Liter (0.26 US gal, 0.22
Imp gal)/h
1.4 Liters (0.37 US gal,
0.31 Imp gal)/h
1.7 Liters (0.45 US gal,
0.37 Imp gal)/h
Ignition system C.D.I. (Capacitor Discharge Ignition) type magneto ignition
Ignition timing B.T.D.C. 20°/
1,400 min
-1
(rpm)
B.T.D.C. 18°/
1,400 min
-1
(rpm)
B.T.D.C. 20°/
1,400 min
-1
(rpm)
Recommended spark plug BPR6ES (NGK)/W20EPR-U (DENSO)
Lubrication system Forced splash
Oil capacity 0.56 Liter
(0.59 US qt, 0.49 Imp qt)
0.58 Liter
(0.61 US qt, 0.51 Imp qt)
0.60 Liter
(0.63 US qt, 0.53 Imp qt)
Recommended oil SAE 10W-30 API service classification SJ or higher
Cooling system Forced air
Starting system
Recoil Starter
Recoil, Recoil and Starter
motor
Recoil, Recoil and Starter
motor
Stopping system Ignition exciter coil circuit open
Carburetor Horizontal type, butterfly valve
Air cleaner Dual type, Dual silent type, Semi dry type,
Oil bath type, Cyclone type
Dual silent type,
Cyclone type
Governor Mechanical centrifugal
Breather system Reed valve type
Fuel used Unleaded gasoline with a pump octane rating 86 or higher
Fuel tank capacity 2.0 Liters
(0.53 US gal, 0.44 Imp gal)
3.1 Liters (0.82 US gal, 0.68 Imp gal)
Reduction
case oil
capacity
Gear type 0.15 Liter (0.16 US qt, 0.13 Imp qt)
Chain type
(without
clutch)
Shared with engine oil
Chain type
(with clutch)
0.50 Liter (0.53 US qt, 0.44 Imp qt)
Clutch Type Centrifugal
Engagement
start
1,800 min
-1
(rpm)
Lock 2,200 min
-1
(rpm)
