Honda GX270 User Manual

42
HELPFUL TIPS & SUGGESTIONS
DRAINING THE FUEL TANK AND CARBURETOR
SEDIMENT CUP
DRAIN SCREW
Place an approved gasoline container below the carburetor, and use
a funnel to avoid spilling fuel.
Remove the carburetor drain bolt and sediment cup, then move the
fuel valve lever to the ON position.
Gasoline is highly flammable and
explosive.
You can be burned or seriously
injured when handling fuel.
Keep heat, sparks and flame away.
Handle fuel only outdoors.
Wipe up spills immediately.
After all the fuel has drained into the container, reinstall the drain
bolt and sediment cup. Tighten them securely.
1.
2.
3.
03/08/21 20:12:52 31ZH9613_043

Honda GX270 Specifications

General

Engine Type	Air-cooled 4-stroke OHV
Bore x Stroke	77 mm x 58 mm
Compression Ratio	8.5:1
PTO Shaft Rotation	Counterclockwise (from PTO shaft side)
Oil Capacity	1.1 L (1.2 US qt)
Ignition System	Transistorized Magneto Ignition
Fuel System	Carburetor
Lubrication System	Splash
Displacement	270 cm3
Net Power Output	6.3 kW (8.4 HP) @ 3, 600 rpm
Starting System	Recoil start
Dry Weight	25.0 kg (55.1 lbs)
Fuel Tank Capacity	5.3 liters
