Honda Interceptor 2014 User Manual

Removing & Installing Body Components u Front Seat
66
Maintenance
Front Seat
❙
Removal
1. Remove the rear seat. 2 P. 65
2. Remove the mounting bolts and collars,
and then pull the front seat back and up.
❙
Installation
1. Install the front seat by aligning the recess
for the current seat height position (low or
high) with the front stay.
2. Install the collars and mounting bolts.
3. Tighten the mounting bolts securely.
4. Make sure that the mount positions of the
recess and the adjust plates are the same
seat position. 2 P. 95
5. Install the rear seat.
Make sure that the seat is locked securely
in position to pull it up lightly.
For the front seat height adjustment, see
“Changing the Front Seat Height.”
2 P. 94
Mounting bolts
Recess (low position)
Front seat
Front stay
Recess (high position)
Collars

Honda Interceptor 2014 Specifications

General

Displacement	782cc
Bore x Stroke	72mm x 48mm
Compression Ratio	11.8:1
Ignition	Computer-controlled digital transistorized with electronic advance
Transmission	6-speed
Final Drive	O-ring-sealed chain
Front Tire	120/70ZR-17 radial
Rear Tire	180/55ZR-17 radial
Rake (Caster Angle)	25.5 degrees
Engine Type	Liquid-cooled 90-degree V-4
Fuel System	PGM-FI with automatic enrichment circuit
Rear Suspension	Pro-Link HMAS single shock with spring preload adjustability
Front Brake	Dual 310mm discs
Rear Brake	Single 256mm disc
Curb Weight	529 pounds
Valve Train	DOHC; 4 valves per cylinder
Fuel Delivery	PGM-FI
Wheelbase (Alternative)	55.5 inches
Front Suspension (Alternative)	41mm inverted HMAS cartridge fork with spring preload, rebound and compression damping adjustability; 4.7 inches travel
Rear Suspension (Alternative)	Pro-Link single shock
Trail	98mm (3.9 inches)
