Wallplate installation
1. Separate wallplate from thermostat.
2. Mount wallplate as shown below.
Mounting screws
CAUTION: ELECTRICAL HAZARD
Can cause electrical shock or equipment damage. Disconnect power before
beginning installation.
MERCURY NOTICE
place the old control in the trash. Contact your local waste management authority for
instructions regarding recycling and proper disposal.
�
Pull here to remove wallplate
from new thermostat.
Remove battery holder.
�
It's easier to grasp the wallplate
and remove it after completely
removing the battery holder.
