Honeywell Voyager 1470g User Manual

Voyager XP User Guide 47
Page Pitch
When you press the Page button on the base or Access Point, the scanners associ-
ated with that base or Access Point will begin beeping (see Page Button). You can
set the pitch of the paging beep for each scanner by scanning one of the following
barcodes. Default = Low.
Error Indicators
Beeper Pitch - Base Error
The CCB01-010BT-V1N base can be configured to beep at a particular pitch when
an error occurs, such as transmission problems to a host system. The beeper pitch
codes modify the pitch (frequency) of the error tone the base emits when there is
an error. Default = Low.
Number of Beeps - Base Error
The number of beeps and LED flashes emitted by the CCB01-010BT-V1N base for
an error condition can be programmed from 1 - 9. For example, if you program this
option to have five error beeps, there will be five error beeps and five LED flashes in
* Low (1000 Hz)
Medium (3250 Hz)
High (4200 Hz)
* Razz (250 Hz)
Medium (3250 Hz)
High (4200 Hz)

Honeywell Voyager 1470g Specifications

General

Operating Temperature	0°C to 50°C (32°F to 122°F)
Environmental Sealing	IP40
Motion Tolerance	Up to 70 cm/s (27.6 in/s) for 13 mil UPC at optimal focus
Storage Temperature	-40°C to 60°C (-40°F to 140°F)
Weight	130 g (4.6 oz)
Humidity	0% to 95% relative humidity, non-condensing
Scan Pattern	Omnidirectional
Connectivity	USB, RS-232, Keyboard Wedge
Decode Capability	Reads standard 1D
Drop Specification	Withstands multiple 1.5 m (5 ft) drops to concrete
Light Levels	0 to 100, 000 lux
Dimensions	62 mm x 169 mm x 82 mm (2.5 in x 6.6 in x 3.2 in)
Light Source	LED
