Honeywell X Series Installation Instruction Sheet

43-TV-33-76 iss.2 GLO Jan 21 UK 3
Next disconnect the inverter high voltage cables by pulling upwards. See Fig 5.
Remove the eight self tapping screws that fix the plastic bezel to the mounting plate. A screw driver with a long shaft will
make this operation much easier. The screws are located one in each corner and one in the centre of each side. See
Fig 6.
Fig 5
Inverter cable
Fig 6
8 screws, to
release front
bezel
