Maintenance
17.
4. Slide the old belt off the drive shaft and then
the end cap. If the belt is broken, remove all the broken
pieces.
5. Place the new belt over the drive shaft first and then the end
cap. Make sure the lettering on the belt is outward facing.
Insert the end cap into the groove.
6. Holding the rotating brush, insert it into the end cap first
and then into the groove on the opposite side.
7. Replace the bottom plate.
3. Firstly lift the side of the rotating brush without the belt
attached. Then lift the end cap where the belt loops
around.
Cleaning the Hard Floor Turbo Tool
Remove the cover and take out the brush for cleaning.
