Security Bracket
The security bracket is secured with two screws. It is not spared.
To remove the security bracket:
1. Prepare the computer for disassembly (see
Preparing to Disassemble the Computer
on page 37).
2. Remove the rear cover (see
Rear Cover on page 38).
3. Remove the two screws that secure the security bracket to the computer.
4. Lift the security bracket straight up and out of the computer.
To install the security bracket, reverse the removal procedures.
74 Chapter 7 Removal and Replacement Procedures All-in One (AIO) Chassis
