Item Component Spare part
number
(1) Display assembly (35.6-cm [14.0-in] HD, anti-glare, touchscreen)
NOTE: Full display hinge-ups are not spared. For display assembly subcomponent spare part
information, see Display assembly subcomponents on page 19.
not spared
(2) Top cover/keyboard (includes touchpad)
NOTE: For a list of country codes, see Top cover/keyboard on page 62.
For use only in HP Notebook PC models:
●
Turbo silver 858078-xx1
●
White silver 858079-xx1
●
Red 858080-xx1
●
Blue 858082-xx1
For use in all models:
●
Black 858077-xx1
(3) Touchpad button board (includes cable) 813517-001
(4) Speakers (left and right) 858083-001
(5) Power button board (includes cable) 813516-001
(6) Power connector cable 813505-001
(7) System board (includes replacement thermal materials):
All system boards use the following part numbers:
xxxxxx-001: Windows 7 or non-Windows operating systems
xxxxxx-601: Windows 10 operating system
HP Notebook PC models with 2 GB of discrete graphics memory:
●
AMD A8-7410 processor 858046-xx1
●
AMD A6-7310 processor 858045-xx1
HP Notebook PC models with UMA graphics memory:
●
AMD A8-7410 processor 858044-xx1
●
AMD A6-7310 processor 858043-xx1
●
AMD A4-7210 processor 858042-xx1
●
AMD E2-7110 processor 858047-xx1
●
AMD E2-7110 processor and 2 GB on-board system memory 858048-xx1
●
AMD E2-7110 processor, 2 GB on-board system memory, and a 32 GB eMMC drive 858049-xx1
HP 245 G5 models:
●
AMD A8-7410 processor 907163-xx1
●
AMD A6-7310 processor 860452-xx1
●
AMD A4-3350B processor 907162-xx1
16 Chapter 3 Illustrated parts catalog
