Item Component Spare part number
(1) Display assembly (not spared)
NOTE: For more display assembly spare part information, see
Display assembly subcomponents on page 36.
(2) Keyboard (includes keyboard cable):
For use in Brazil 698694-201
For use in India 698694-D61
For use in Latin America 698694-161
For use in South Korea 698694-AD1
For use in Taiwan 698694-AB1
For use in Thailand 698694-281
For use in the United States 698694-001
(3) Power button board (includes cable) 685098-001
(4) Top cover (includes TouchPad)
For use in charcoal models 685762-001
For use in black models 713530-001
(5) Speakers (includes left and right speakers and cable) 685106-001
(6) TouchPad button board (includes bracket and cables) 685099-001
(7) Fan/heat sink assembly (includes replacement thermal materials):
For use only with computer models equipped with an AMD processor 688281-001
For use only with computer models equipped with an Intel processor and a graphics
subsystem with discrete video memory
685087-001
For use only with computer models equipped with an Intel processor and a graphics
subsystem with UMA video memory
685086-001
Hard Drive Hardware Kit, includes: 685089-001
(8a) Hard drive cable
(8b) Hard drive bracket
Plastics Kit, includes: 685100-001
(9a) Hard drive compartment cover (includes one captive screw, secured by a C-clip)
(9b) Memory module/wireless module compartment cover (includes one captive screw, secured by a C-clip)
NOTE: See
Plastics Kit on page 39 for more Plastics Kit spare part information.
(10) Optical drive cable (includes cable bracket) 685084-001
(11) USB board (includes cable) 685097-001
(12) System board (includes replacement thermal materials):
For use only with computer models equipped with an AMD E2-2000 processor
Computer major components
31
