Assembly Replacement
Procedure 14. W3 Line Switch Cable (8560E)
Procedure 14. W3 Line Switch Cable (8560E)
Removal
NOTE To remove the line switch for 8560EC instruments see “Removal of the
Line Switch from the Front Panel” on page 153.
WARNING Due to possible contact with high voltages, disconnect the
spectrum analyzer line-power cord before performing this
procedure.
1. Remove the spectrum analyzer cover assembly as described in
"Procedure 1. Spectrum Analyzer Cover."
2. Fold out the A2, A3, A4, and A5 assemblies as described in steps 3
through 5 under "Procedure 5. A2, A3, A4, and A5 Assemblies
Removal."
3. Disconnect A1A1W1 from A3J602.
4. Place the spectrum analyzer top-side-up on the workbench with A2
through A5 folded out to the right.
WARNING The voltage potential at A6A1W3 is +9 kV. Disconnect at the
CRT with caution! Failure to properly discharge A6A1W3 may
result in severe electrical shock to personnel and damage to the
instrument.
5. Connect the spectrum analyzer line-power cord to provide proper
grounding while discharging the A6A1W3 post-accelerator cable.
Make sure that the spectrum analyzer line-power switch is in the off
position.
6. Connect a high voltage probe (1000:1), such as the HP 34111A, to a
voltmeter with a 10 megohm input.
7. Connect the clip lead of the probe (ground) to the chassis of the
spectrum analyzer.
8. Slip the tip of the high voltage probe under the A6A1W3
post-accelarator cable rubber shroud to obtain a reading on the
voltmeter. See Figure 3-3 on page 162.
9. Keep the high voltage probe on the post-accelerator connector until
the voltage has dropped to a voltmeter reading of less than 5 mV
(less than 5 V at the connector). This normally takes about 30
seconds.
10.Disconnect the line-power cord from the spectrum analyzer.
