HP 8560E Service Manual

Chapter 2 59
Adjustment Procedures
Using the TAM
6. Log Fidelity Synthesizer/Level
Generator
HP
3335A
Test Cable BNC HP 10503A
7. Sampling Oscillator Manual Probe Cable
8. YTO Frequency Counter
(3 to 6.8 GHz)
HP 5342A,
HP 5343A
9. LO Distribution
Amplifier
Power Meter HP 8902A,
HP 436A,
HP 438A
Power Sensor (3 to 6.8 HP 8485A
GHz, 10 to 20 dBm)
10. Low Band Flatness Source (10 MHz to 2.9
GHz)
HP 8340A/B
Power Meter HP 8902A,
HP 436A,
HP438A
Power Sensor HP 8482A,
HP 8481A
(10 MHz to 2.9 GHz)
Power Splitter HP 11667B
(10 MHz to 2.9 GHz)
11. Calibrator Amplitude Power Meter HP 8902A,
HP 436A,
HP 438A
Power Sensor
HP
8482A,
HP 8481A
12. 10 MHz Reference Frequency Counter HP 5342A,
HP 5343A
Oscillator (9 to 11 MHz)
13. External Mixer Bias Manual Probe Cable
14. External Mixer
Amplitude
Power Meter HP 8902A,
HP 436A,
HP 438A
Power Sensor
(310.7 MHz, −25 to −35
HP 8481D,
HP 8484A
dBm)
Source (310.7 MHz, −30 dBm) HP 8340A/B
Table 2-5 Required Test Equipment for TAM
Adjustment Equipment Used
Required
Model
Recommended
Model
