brief Displays PoE information for each port. See Viewing PoE status on all ports on page
119.
<port-list> Displays PoE information for the ports in port-list. See Viewing the PoE status on
specific ports on page 121.
<slot-id-
range>
Displays PoE information for the selected slots. See Showing the PoE information by
slot).Enter the all option to display the PoE information for all slots.
The show power-over-ethernet displays data similar to that shown in show power-over-ethernet
command output on page 119.
show power-over-ethernet command output
switch(config)# show power-over-ethernet
Status and Counters - System Power Status
Pre-standard Detect : On
System Power Status : No redundancy
PoE Power Status : No redundancy
Chassis power-over-ethernet
Total Available Power : 600 W
Total Failover Power : 300 W
Total Redundancy Power : 0 W
Total Used Power : 9 W +/- 6W
Total Remaining Power : 591 W
Internal Power
1 300W/POE /Connected.
2 300W/POE /Connected.
3 Not Connected.
4 Not Connected.
External Power
EPS1 /Not Connected.
EPS2 /Not Connected.
Viewing PoE status on all ports
Syntax:
show power-over-ethernet brief
Displays the port power status:
PoE Port
Lists all PoE-capable ports on the switch.
Power Enable
Shows Yes for ports enabled to support PoE (the default) and No for ports on which PoE is
disabled.
Power Priority
Lists the power priority (Low, High, and Critical) configured on ports enabled for PoE. (For
more information on this topic, see Configuring PoE operation on page 109.)
Alloc by
Displays how PoE is allocated (usage, class, value).
Table Continued
Chapter 4 Power Over Ethernet (PoE/PoE+) Operation 119
