HP Compaq nx6110 User Manual

Product Description
Maintenance and Service Guide 1–15
Table 1-5
Standard Keyboard Components
Item Component Function
1 f1 to f12 keys (12) Perform system and application tasks.
When combined with the fn key, several
keys and buttons perform additional tasks
as hotkeys.
2 caps lock key Enables caps lock and turns on the caps
lock light.
3 fn key Executes frequently used system
functions when pressed in combination
with a function key or the esc key.
4 Windows logo key In Windows, displays the Windows
Start
menu.
5 Windows
applications
key
In Windows, displays a shortcut menu
for
items beneath the pointer.
6 Arrow keys Moves the cursor around the screen.
7 Keypad keys (15) In Windows, can be used like the keys
on
an external numeric keypad.
8 num lock key Enables numeric lock, turns on the
embedded numeric keypad, and turns
on
the num lock light.

HP Compaq nx6110 Specifications

General

Storage	40 GB to 80 GB HDD
Optical Drive	DVD-ROM or DVD/CD-RW combo
Battery	6-cell Lithium-Ion
Battery Life	Up to 4 hours
Weight	2.7 kg (6.0 lbs)
Processor	Intel Pentium M or Intel Celeron M
RAM	Up to 2 GB DDR SDRAM
Display	15.0-inch XGA TFT
Graphics	Intel GMA 900
Operating System	Windows XP Professional
Networking	10/100 Ethernet
Ports	USB 2.0, VGA, headphone, microphone, RJ-11, RJ-45
Expansion Slots	1 x Type I/II PC Card
