Page #40 background image
Input devices of this product comply with ISO 9241, part 9.
Plastics parts weighing over 0.055 pounds (25 grams) used in the product are
marked per ISO 11469 and ISO1043.
This product contains 0% recycled materials (by wt.)
This product is greater than 85% recycle-able when properly disposed of at
end of life.
Packaging
Packaging Materials
External:
Corrugated Paper – 1.27 lb (574 g)
Internal:
Corrugated Paper
– 0.10 lb (45 g)
PET Bag/Banding – 0.12 lb (56 g)
The plastic packaging material is made from 20% recycled content.
The corrugated paper packaging materials contains at least 80%
recycled content.
HP follows these guidelines to decrease the environmental impact of product
packaging:
Eliminate the use of heavy metals such as lead, chromium, mercury and
cadmium in packaging materials.
Eliminate the use of ozone-depleting substances (ODS) in packaging
materials.
Design packaging materials for ease of disassembly.
Maximize the use of post-consumer recycled content materials in
packaging materials.
Use readily recyclable packaging materials such as paper and
corrugated materials.
Reduce size and weight of packages to improve transportation fuel
efficiency.
Plastic packaging materials are marked according to ISO 11469 and DIN
6120 standards.
Material Usage
This product does not contain any of the following substances in excess of
regulatory limits (for reference of these limits please refer to the HP General
Specification of the Environment
(
http://www.hp.com/hpinfo/globalcitizenship/environment/
supplychain/gen_specifications.html
):
Asbestos
Certain Azo Colorants
Certain Brominated Flame Retardants – may not be used as flame
retardants in plastics
Cadmium
Chlorinated Hydrocarbons
Chlorinated Paraffins
Formaldehyde
Halogenated Diphenyl Methanes
QuickSpecs
HP Compaq nx9420 Notebook PC
Technical Specifications
DA - 12427 North America — Version 22 — October 5, 2007
Page 40

Other manuals for HP Compaq NX9420

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Compaq NX9420 and is the answer not in the manual?

HP Compaq NX9420 Specifications

General IconGeneral
HDD speed5400 RPM
HDD interfaceSATA
Optical drive typeDVD Super Multi DL
Total storage capacity100 GB
Display diagonal17 \
AC adapter power90 W
Audio systemHP Premier Sound high-definition Audio 24-bits audio DAC, Digital EQ
Number of built-in speakers2
Bus typeFSB
SteppingC0
Tjunction100 °C
Cache external2048 KB
Processor cache2 MB
Processor modelT2400
System bus rate- GT/s
Processor familyIntel® Core™ Duo
Processor seriesIntel Core Duo T2000 Series
Processor socketSocket 478
Processor codenameYonah
Processing Die size90 mm²
Processor frequency1.83 GHz
Processor cache typeL2
Processor technologyIntel Centrino Duo Mobile
Processor lithography65 nm
Processor manufacturerIntel
Processor front side bus667 MHz
Processor operating modes32-bit
ECC supported by processorNo
Thermal Design Power (TDP)31 W
CPU multiplier (bus/core ratio)11
Number of Processing Die Transistors151 M
Storage temperature (T-T)-40 - 80 °C
Operating temperature (T-T)0 - 80 °C
Operating relative humidity (H-H)10 - 90 %
Non-operating relative humidity (non-condensing)5 - 95 %
Memory slots2x SO-DIMM
Internal memory1 GB
Internal memory typeDDR2-SDRAM
Maximum internal memory4 GB
Internal modemYes
Expansion slots1 Type I/II PC Card slot supports 32-bit CardBus, 16-bit cards, 7 in 1 media reader: Secure Digital, MultiMediaCard, Memory Stick, Stick Pro or Stick Duo, Smart Media and xD memory cards
Dimensions (WxDxH)33 x 393 x 275 mm
Wireless technologyIntel Wireless LAN 802.11a/b/g, MOW2, Bluetooth
Diskette drive memoryNo MB
Video card featuresATI Mobility Radeon X1600
Bundled softwareMicrosoft Windows Media Player 10, Microsoft Direct X9 Adobe Acrobat Reader, HP software voor sneltoetsen, HP Wireless Assistant, HP ProtectTools, HP Backup- en recoveryoplossing, HP Mobile printerdriver, HP OpenView Radia Management Agent, InterVideo WinDVD
Operating system installedWindows XP Professional
Motherboard chipsetIntel® 945PM Express
Battery life (max)4 h
Number of battery cells8
Networking featuresBroadcom Gigabit (10/100/1000 NIC) PCI Express Ethernet controller
Cable lock slot typeKensington
Discrete graphics card modelAMD Mobility Radeon X1600
Maximum graphics card memory0.256 GB
TV-out typeS-Video
Charging port typeDC-in jack
USB 2.0 ports quantity4
Parallel ports quantity0
CardBus PCMCIA slot typeType II
Firewire (IEEE 1394) ports1
Processor ARK ID27235
Processor package size35 x 35 mm
Country of originChina
Weight and Dimensions IconWeight and Dimensions
Depth393 mm
Width33 mm
Height275 mm
Weight3350 g
